S.Internationals PC-D Series Connectors is for catering to needs for a dependable and versatile electrical connection solution.
In environments where efficiency and safety are paramount, the PC-D Series Connectors excel by providing a robust connection for various industrial applications such as power distribution, machinery, and automation systems. With a 125 amp rating and a rated voltage of 2KV, these connectors ensure reliable performance even under demanding conditions.
Designed with a 4-pin configuration, including 3 Phase and 1 Earth contact, the PC-D series allows for seamless integration into existing infrastructures. The IP65 compliant rugged steel housing offers outstanding durability, ensuring that these connectors can withstand harsh environments and maintain performance over time
| Number of contacts | 5 Contacts (3Phase, 1- Neutral, 1-Earthing) |
| Rated voltage | 2KV AC/DC |
| Rated current | 125 to 200A |
| Terminal type | crimp connection |
| Wire gauge | Upto 50 mm² |
| IP rating (IEC 60529, IP code) | When mated: IP65 Receptacle with lid closed: IP65 |
| Shock, Vibration (IEC 61373) | Category 1, Class B |
| Operating temperature | - 50 °C … + 85 °C |
| Mechanical endurance (IEC 60512-9-1) | 500 mating cycles |
